| اسم العلامة التجارية: | DONJOY |
| رقم الطراز: | NO.ERK311 |
| الـ MOQ: | Negotiation |
| السعر: | قابل للتفاوض |
| تفاصيل التعبئة: | Carton, Wooden Case |
| شروط الدفع: | T/T,L/C, Credit Card |
Elliptical Pressure Vessel Manhole Covers Stainless Steel SS304 SS316L 435mm*335mm
Quick Detail
Manhole Cover,Manway
Size:435*335mm,530*430mm,535*435mm,635*525mm
Type: Round pressure
Gasket: EPDM,NBR,SILICONE,
HEIGHT:75-80mm,90-100mm,130-160mm
Working Pressure:0.5-3Bar
Polished: Mirror, Mattr, Ra≤0.8μm,Ra≤0.5μm
Handle: Stainless Steel
Specification
|
Product Name: |
Elliptical Pressure Vessel Manhole Covers Stainless Steel SS304 SS316L 435mm*335mm |
|
Material: |
AISI304, AISI316L |
|
Size: |
DN200,220,300,350,400,430,450,500,600,700,800mm |
|
Finish: |
Ra ≤0.8um,Mirror, 320Grit, 180Grit, 240Grit |
|
Connection: |
Welded, Flange |
|
Thickness |
Stanadard or customized |
|
Certificate: |
CE, ISO9001/2008, 3A |
|
Application scope: |
Dairy, food, beer, beverage, pharmacy, cosmetic,Oil,Waste water etc |
|
Packaging Details: |
Shrink wrapped - carton - pallet . Or as per the request of customers |
Application
Manhole cover with pressure always used for pressure vssel in the field of food,
beverage,chemical etc. And installation on the side or top of tank.
