| اسم العلامة التجارية: | DONJOY |
| الـ MOQ: | Negotiation |
| تفاصيل التعبئة: | Carton, Wooden Case |
| شروط الدفع: | T/T,L/C, Credit Card |
Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend
Quick Detail
Fitting Elbow, Bend, Long radius fittings
Specification
|
Product Name: |
Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend |
|
Material: |
AISI304, AISI316L |
|
Size: |
1/2"-10" |
|
Finish: |
Sandblasting |
|
Connection: |
weld ends,socket Welding |
|
Standard: |
Sch10,Sch20,SCH40,SCH80,SCH5, JIS,DIN,INCH |
|
Certificate: |
ISO,3A,CE |
|
Application scope: |
Dairy, food, beer, beverage, pharmacy, cosmetic, Oil,Chemical |
|
Packaging Details: |
Shrink wrapped - carton - pallet . Or as per the request of customers |
Donjoy 90 Degree Elbow and fittings compliant with USA 3-A sanitary standard, constructed from sanitary stainless steel 304 or 316L, provide solid, durability, problem-free for weld or assemble, available in ASME BPE, 3-A, DIN, SMS, ISO, I-line standard. 90 Degree Elbow and fittings widely used in food and beverage, brewing, pharmaceutical industries.
Donjoy Technology as 90 Degree Elbow Manufacturer in China, manufacture sanitary pipe fittings, sanitary valve, pump for more than 27 years. With USA 3-A, FDA, EU CE certification.
| Size (Tube OD) | Dimensions | ||||
| Outside Dimension | Wall Thickness | A | B | Radius | |
| 1/2″ | 0.500″ | 0.065″ | 3.000″ | 3.250″ | 0.750″ |
| 3/4″ | 0.750″ | 0.065″ | 3.000″ | 3.375″ | 1.125″ |
| 1 “ | 1.000″ | 0.065″ | 2.063 | 2.563″ | 1.500″ |
| 1-1/2″ | 1.500″ | 0.065″ | 2.938″ | 3.688″ | 2.250″ |
| 2 “ | 2.000″ | 0.065″ | 4.063″ | 5.063″ | 3.000″ |
| 2-1/2″ | 2.500″ | 0.065″ | 5.188″ | 6.438″ | 3.750″ |
| 3 “ | 3.000″ | 0.065″ | 6.313″ | 7.813″ | 4.500″ |
| 4 “ | 4.000″ | 0.083″ | 8.313″ | 10.313″ | 6.000″ |
| 6 “ | 6.000″ | 0.109″ | 11.000″ | 14.000″ | 9.000″ |
Tag : BPE ELBOW, Sanitary fitting elbow, Donjoy elbow
